19.07.2019
CPC518 CPU Module in the CompastPCI Serial format is built on Intel Xeon-D CPU family and is available in five versions. Among them are the versions equipped with Intel Xeon D-1519, Xeon D-1539 and Xeon D-1559, the amount of RAM varies from 16 to 32 GB. Depending on the performance, the temperature range is changing as well: the user can choose a device, operating either in the range from 0 to +70 °С or from -40 to +85 °С.
As is usually the case with the CPU modules, focused on solving the server-class problems, CPC518 is equipped with 2 x 10Gb Ethernet ports (2 x channels SPF+, support of Fibre Channel PCS modules), 1Gb Ethernet port, 4 x USB 2.0 ports and 4 x USB 3.0 ports, 6-channel SATA interface with support of RAID 0, 1, 5, 10 and runs under Linux 3.19; QNX 6.5.0; Microsoft Windows Embedded Standard 7 or 10. The module is also equipped with DisplayPort interface for output of video stream with the resolution up to 1920х1440@60 Hz.
The main application areas of CPC518 can include creation of modular server-based solutions of CompactPCI format, data processing centers, data storage systems, resource-intensive calculations in a wide variety of manufacturing sectors, where high capacity and scalability of computer systems is required.
For more information please contact us by this email: info@fastwel.сom
